Phuentsholing Township Development Project
Phuentsholing Township Development Project
Stakeholder Meeting conducted on April 08, 2024
Program for Mr. Ernesto H. Braam, Alternate Executive Director, Board of Director, ADB.
They are used for installation of underground infrastructure or utilities (such as gas mains, water mains, communication lines and pipelines) that would be obstructive or easily damaged if placed above ground. Trenches are needed later for access to these installations for service.
An elevated service reservoir (ESR) is a structure that supplies water to a region by gravity and pressure. ESRs are built when water is to be supplied at an elevated height or when the distance is large and the topography is undulating. ESRs are generally at a height of more than 15 meters.
Excavation works, Pcc bed leveling and compaction in progress for Ground Service Reservoir has been completed
44m span Cantilever Bazaam (traditional wooden bridge) for Omchhu. In this project, the key components of bazaam are concrete and steel members instead of woodstructure and Steel truss pedestrian bridge over Open Outfalls
Omchu Bazam and PEDESTRIAN BRIDGE OVER OPEN OUTFALLS
SWTY – to control and process solid and biodegradable waste generated from upcoming future town.
RRM height and width checked and stone bond formwork checked prior to concreting. stone shapes.
RRM wall alignment and dimensions checked.
A sewerage network, also known as a wastewater collection system, is a network of pipes, pumping stations, and other components that convey sewage from its source to a treatment and disposal point.
A stormwater network is a system of pipes, channels, and structures that carry stormwater to bodies of water like lakes, streams, rivers, and ponds. Stormwater is rainwater that drains from impervious surfaces like parking lots, sidewalks, paved streets, and roofs.
HDPE pipe laying in designated and respective streets for water supply network.
11.647 km of straight pipe lines. And multiple road crossing and plot connections
